I/O Sensor

  • These image sensors have 1.5mega pixels(1,200 x 1,650) with pixel size of 20 x 20um(attempting to 10 x 10um) and monitor photodiode for imaging and detecting X-ray irradiation.
  • FOP(Fiber Optic Plate) materials is used as the input interface high image quality(Over HD level) and duration of sensor life time even under large amount of X-ray inspection and exposure.
  • Various products types are available with different products configurations and scintillators used for.
  • XDP-350 series are available with USB 2.0 & 3.0 connections. In addition, XDP-350 series can be provided as module state product excluding housing and cable assembly.
  • Finally, XDP-350 warranty is for 2 years for now but negotiable with clients.

Item Intra-Oral Sensor
Model XDP-F350A XDP-G350A
External Dimensions Detector 43.4 x 33.7 x 5.4 (#2.0) 43.4 x 33.7 x 4.2 (#2.0)
Active Surface in Size 26.24mm x 34.4mm
Pixel Size 20um
Theoretical Detector Resolution 20 lp/mm
Scintillator Technology FOS GOS
Gray Levels 14bits
Dynamic Range 62dB
Full Well Capacity 600,000 Electrons
Frame Rate 0.6fps
Connection Standard USB 2.0 & 3.0 High Speed
